- High speed
- Ultra-high reliability
- Low insertion loss
The NanoSpeedTM Series 1×2 solid-state fiber optic switch connects optical channels by redirecting an incoming optical signal into a selected output optical fiber. This is achieved using patent non-mechanical configurations with solid-state all-crystal designs, which eliminates the need for mechanical movement and organic materials. The NS fiber optic switch is designed to meet the most demanding switching requirements of ultra-high reliability, fast response time, and continuous switching operation. This series of switches are bidirectional intrinsically.
Agiltron’s PCB driver listed in the web is recommended to operate this device, featuring high efficiency and low cost with 12V DC power and TTL control signal.
|NanoSpeed Series 1×2 Switch||Min||Typical||Max||Unit|
|Central wavelength ||780||1650||nm|
power switch only)
|PDL (SMF Switch only)||0.15||0.3||dB|
|PMD (SMF Switch only)||0.1||0.3||ps|
|ER (PMF Switch only)||18||25||dB|
|IL Temperature Dependency||0.25||0.5||dB|
|Response Time (Rise, Fall)||30||300||ns|
|Fiber Type||SMF-28, Panda PM, or equivalent|
|Repeat Rate||5kHz driver||DC||5||kHz|
|Normal power switches||300||mW|
|High power switches||5||W|
 Operation bandwidth is +/- 25nm approximately at 1550nm.
 Measured without connectors. For other wavelength, please contact us.
 Defined at 1310nm/1550nm. For the shorter wavelength, the handling power may be reduced, please contact us for more information.
