Micro-Optic Fiber Analog Modulators - NanoSpeed™

(ultra-fast: 200ns, nonmechanical, vibration insensitive, broad operating wavelength, low loss)

The NanoSpeed™ High-Speed Variable Optic Attenuator family features ultra-fast sub-millisecond response, nonmechanical high reliability, and a wide operating temperature range from -50°C to +90°C. These VOAs are designed to meet the most mission-critical high-speed optical switching applications. The patent-pending NanoSpeed™ VOA is nonmechanical, controlled by an electrical field inside an inorganic optical crystal to facilitate fast light intensity control. The output light intensity is highly stable against environmental variations with a compensation technique. With an integrated electronic driver, the switch is conveniently controllable by a low voltage with a speed up to 150kHz. The high-speed VOA can also be operated at a fixed 5MHz with full attenuation. With partial attenuation, the high-speed VOA can be modulated up to 500kHz.
An evaluation/development kit including a driving circuit is available for these products.

DC-1MHz Driver for NanoSpeed™ Variable Optic Attenuator
we make custom electronic circuits for all application scenarios
SKU: NVDR

Configurations

5 MHz Resonance Fiber Optical Modulator – NanoSpeed™
5MHz, High Power, Bidirectional
SKU: NSRM
90 MHz Resonance Fiber Optical Modulator – NanoSpeed™
10 to 90MHz, High Power, Bidirectional
SKU: NSRM
High Speed Variable Fiber Optical Attenuator 950-2400nm, 18dB
100 kHz, bidirectional, SMF, PMF, 10W, single stage
$649+
SKU: NVOA, NHOA
$649 – $1,450
This product has multiple variants. The options may be chosen on the product page
High Speed Variable Fiber Optical Attenuator 950-2400nm, 35dB
100 kHz, bidirectional, SMF, PMF, 10W, dual stage
$1150+
SKU: NVOA, NHOA
$1,150 – $1,850
This product has multiple variants. The options may be chosen on the product page
Small Amplitude/Phase Modulator 350-2400nm, High Linearity
DC-1MHz 10%, low power consumption, up to 10W
$1250+
SKU: NSSM
$1,250
This product has multiple variants. The options may be chosen on the product page
High Speed Broadband Variable Optical Attenuator 950-2400nm, 120nm Coverage
100 kHz, 18dB, bidirectional, SMF, PMF
$1050+
SKU: NSBA
This product has multiple variants. The options may be chosen on the product page
$1,050
This product has multiple variants. The options may be chosen on the product page
High Speed Multi-Mode Variable Fiber Optical Attenuator 50 μm Core
350nm-2400nm, 100 kHz, 20dB, bidirectional
$1100+
SKU: NMOA, NHMA
$1,100
This product has multiple variants. The options may be chosen on the product page
High Speed Multimode Broadband Variable Fiber Optical Attenuator 200nm, 50 μm Core
350-2400nm, 100 kHz, 20dB, bidirectional, 200nm wavelength coverage, 50 μm fiber
$1350+
SKU: NMOA
$1,350
This product has multiple variants. The options may be chosen on the product page
High Speed Premium Broadband Variable Optical Attenuator 350-2400nm, 120nm Coverage
1MHz, SMF, PMF, high power, bidirectional, up to 10W
$1395+
SKU: NPBA
$1,395 – $3,590
This product has multiple variants. The options may be chosen on the product page
Precision High Speed Optical Attenuator
350-2400nm, <1 μs response, up to 10W, 1.5dB loss, 0.1dB repeatability, SM, PM, MM, USB/RS232
$1495+
SKU: PNSA
$1,495 – $2,450
This product has multiple variants. The options may be chosen on the product page
High Speed Variable Fiber Optical Attenuator Array (up to 48 Channels)
$6560+
SKU: NSAA
$6,560
This product has multiple variants. The options may be chosen on the product page
High Speed Optical/Laser Power Regulator/Stabilizer/Noise Reduction
100ns rise/fall, low loss, bidirectional, polarization insensitive, 350-2400nm
SKU:
$1630+
Precision Variable Optical Attenuator Programmable Array System
net-ready, precision feedback control, high speed, SM/MM, broadband
$2574+
SKU: VOAS
$2,574 – $22,704
This product has multiple variants. The options may be chosen on the product page
