Ultra High Power UV Curing Light/Lamp

Enquire Now
(ultra-bright paper burning)

This UV curing light burns paper with an output power density exceeding legacy mercury UV lamps, and comes with a 1-year manufacturer warranty against LED burnout. It is the most powerful device on the market, providing the benefits of shorter processing time as well as stronger and deeper curing. The 365nm UV light features compact size, ease of use, and longevity. The UV light can be switched on/off either by a finger press or a foot pedal and has a timer ranging from 10 sec to 60 min. The design leverages military gear development expertise, realizing a ruggedized professional-grade hand-held tool that is widely used in optical and medical device assemblies.

A wand stand, goggles, and foot pedal are also separately available for purchase.

$1,180.00

$1,180.00

(ultra-bright paper burning)

64 in stock (can be backordered)

  • Long Operation hour
  • High Power
  • Compact
  • Low Cost



  • UV adhesive cure
  • UV coating
Parameter Description Unit
Wavelength     365±5, 385±5 nm
UV irradiance 4.0 – 5.0 * W/cm2
Cure time Max. 60 Sec. or 60 Min
UV spot size Φ4 mm
UV cure distance 20 mm
Cooling method air blowing
Operation life 10,000 hours



* Average intensity over the spot size Φ4mm at working distance

P/N: SUVA-011111031
