SKU: FFST

The Ultra-Broadband Fast Fiber Optical Shutter is based on a micro-electro-mechanical system (MEMS) fiber-to-fiber direct coupling platform driven by a fast piezo actuator. It uniquely offers near-perfect performances that are unmatched in the industry, including ultra-low insertion loss of 0.2dB, ultra-broadband from 200 to 2100nm, high blocking level >65dB, high optical power handling up to 1W (for small core fiber this is an option). Light passes through the device with a thin index-matched gap without any optical coatings. It is available with all types of fibers having a 125-micron outer diameter. Other diameter fibers can be accommodated with special order.

The Shutter is integrated with a PCB having USB with GUI software and four sub-mount pins: two for 0-5V DC power input and two for 0-5V control input.

Single-Mode Selection

Fiber Type	SM300	SM400	SM450	SM600	Hi780	SM800	SM980	Hi1060	SM28	SM2000
Wavelength Range	320 – 430 nm	405 – 532 nm	480 – 650 nm	620 – 650 nm	760 – 800 nm	830 – 870 nm	980 – 1550 nm	960 – 1080 nm	1020 – 1900 nm	1.7 – 2.3 µm
Insertion Loss	<1.2 dB	<1 dB	<1 dB	≤0.8 dB	≤0.6 dB	≤0.5 dB	≤0.5 dB	≤0.4 dB	≤0.2 dB	≤0.5 dB
Maximum Attenuation	50 dB	50 dB	50 dB	50 dB	50 dB	50 dB	50 dB	50 dB	48 dB	48 dB
Max Optical Power	50mW	50mW	50mW	0.1W	0.3W	0.3W	0.3W	0.3W	0.8W	0.8W
Polarization DL	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB	0.2 dB@20dB
Return Loss	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB
Operating Temperature	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C
Storage Temperature	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C	-50 to 85°C
Datasheet
Price	$869	$869	$869	$769	$709	$689	$689	$739	$329	$669

Polarization-Mode Selection

Fiber Type	PM350	PM405	PM460	PM630	PM780	PM850	PM980	PM1550	PM1950
Wavelength Range	350 – 460 nm	400 – 680 nm	460 – 700 nm	620 – 650 nm	760 – 800 nm	830 – 870 nm	960 – 1080nm	1260 – 1650nm	1850 – 2200nm
Insertion Loss	≤1.2 dB	≤1.1 dB	≤0.9 dB	≤0.9 dB	≤0.8 dB	≤0.7 dB	≤0.6 dB	≤0.2 1dB	≤0.8 dB
Max Attenuation	50 dB	50 dB	50 dB	50 dB	50 dB	50 dB	35 dB	35 dB	70 dB
Extinction Ratio	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB
Return Loss	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB
Max Power	500mW	500mW	500mW	500mW	500mW	500mW	500mW	500mW	500mW
Operating Temperature	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C
Storage Temperature	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C	-50 to 90°C
Datasheet
Price	$1,329	$1,329	$1,329	$1,329	$1,329	$1,149	$829	$449	$1,149

Multi-Mode Selection

Fiber Type	GIF50	GIF625	FG50LGA	FG105LCA	FG10LDA
Wavelength Range	800 – 1600 nm	800 – 1600 nm	400 – 2400 nm	400 – 2400 nm	700 – 1000 nm
Insertion Loss	≤0.5 dB	≤0.5 dB	≤0.8 dB	≤1 dB	≤1 dB
Maximum Attenuation	30 dB	30 dB	30 dB	20 dB	25 dB
PDL	0.01 dB	0.01 dB	0.01 dB	0.01 dB	0.01 dB
Return Loss	≥35 dB	≥35 dB	≥35 dB	≥35 dB	≥35 dB
Max Optical Power	1W	1W	1W	1W	1W
Operating Temperature	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C	-40 to 80°C
Storage Temperature	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C	-40 to 85°C
Datasheet
Price	$469	$469	$489	$709	$489
